Department of Electrical & Electronics Engineering

Power Systems

Master of Technology (M. Tech.) in Power Systems is a 2 year full time professional postgraduate course offered by Department of Electrical and Electronics Engineering and was started in the year 2019. The course comprises state-of-art techniques such as Advanced Power System Analysis, Power System Operation & Control, advanced computing techniques applied to electrical systems, digital protection schemes, Stability Evaluation Planning, Power Electronics and control, Reliability and Forecasting, Wind and Solar Energy Electric Conversion Systems, etc,. The curriculum structure and course contents introduces unprecedented challenges and wide scope for power and energy systems research which open up new opportunities to young Power Engineers. Major research areas include sustainable, economic, efficient and reliable energy conversion, generation, transmission, distribution, storage and utilization of electric energy, including application of power electronics and Artificial Intelligence in power system operation and control. Facilities include Power Systems Lab, Microprocessors and Embedded Systems Lab, Power Electronics & Drives Lab, Electrical Machinery Lab, Control systems lab, Computer lab Departmental Library. The research laboratory includes most modern DSTATCOM, Power Quality analysers, Solar and wind emulators, Fuel Cell units, IGBT based inverter, FPGA and PWM cards, PLC training kit, TMS DSP kits and Simulation facilities with softwares like MATLAB, MiPower, PSCAD, Lab VIEW, ANSYS, etc. The department has links with industry and a well-connected alumni network. Power engineers work in a wide variety of industrial and commercial facilities after their M.Tech in Power Systems. Some of the major companies where the Alumni of the course are placed includes ABB, L&T, Robert Bosch, Tata Elxsi, ………etc….

PO1: Technical Knowledge/ Degree of Mastery: An ability to demonstrate a degree of mastery in the field of power systems.

PO2: Design and Development: An ability to apply the knowledge acquired in power systems to design and develop solutions for real world problems by following the standards.

PO3: Research Skills: An ability to independently carry out investigation, research and development work to propose creative and innovative solutions in power systems and allied arena.

PO4: Technical Communication Skills: An ability to communicate effectively, write and present technical reports on complex engineering activities by interacting with the engineering fraternity and with the society at large.

PO5: Modern Tool Usage: An ability to identify, select and apply appropriate techniques, resources and state-of-the-art tools to model, analyse and solve practical engineering problems.

PO6: Ethical Practice and Social Responsibility: An ability to engage in life-long learning for the design and development related to the Power Systems related problems taking into consideration sustainability, societal, ethical and environmental aspects.

PO7: Multidisciplinary Work and Management skills: Ability to work in a team of engineers/ researchers of various disciplines and specializations to take up multidisciplinary development projects involving managerial and financial challenges which may lead to Entrepreneurship and solutions viable to Industry.

PO8: Smart Grid: (PSO1): Ability to design, analyse, maintain and modify electricity network that use digital technologies, control strategies, sensors, modern instruments and software to better match the supply and demand of electricity in real time while minimizing costs and maintaining the stability and reliability of the standalone and/or interconnected power grid.

PO9: Power system optimization,Green Energy and Power Quality: (PSO2):Ability to suggest, design, promote and execute cheap and environment friendly, optimal power generation utilizing minimum natural resources and to assure quality power for sustainable development

PEO 1. Produce technically competent Power and Energy System graduates capable of designing, analysing, monitoring implementing and improvising the power systems to effectively facilitate electricity generation, transport and utilization as demanded by the industrial needs, as engineers, researchers, consultants, teachers or entrepreneurs working in tune with the global societal requirements on electrical energy.

PEO 2. Identify and address the current and futuristic challenges and problems in power systems, and to develop feasible and viable solutions in an economic, social, ethical and environmental context assuring efficient , economic and stable power system operation.

PEO 3. Inculcate managerial, leadership and other soft and hard skills to effectively communicate in the power system environment and to pursue core power system research, following professional ethics, scientific logic and commitment towards sustainable development in a global scenario.

At the Department of EEE, GCE Kannur we have the following hardware setup.

1) Grid Connected Three Phase Inverter with Power Quality Improvement

The complete system was assembled in our lab using Semikron inverter module (three phase), LEM sensors (voltage and current measurement), 6N136 based gate drive, interfacing inductor and RC ripple filter. The system can operate as a DSTATCOM (providing power quality improvement) or as a renewable energy based inverter (active power injection + power quality improvement). The variety of local loads can be connected. (Non linear, RL, combined). The complete system is controlled using dSpace MicroLab Box. For the control purpose, Matlab/Simulink and Controldesk softwares are used.

Photo of grid connected three phase inverter along with host PC, Power quality analyser and DSO

Grid connected three phase inverter with different loads

Grid connected three phase inverter – Semkron module and gate driver (top rack), LEM sensors (middle rack), Interfacing inductor and RC ripple filter (bottom rack)

2) Wind Turbine emulator – PV emulator – Fuel cell - Battery Based Microgrid System (With grid connection)

This microgrid system consists of a wind turbine emulator, PV emulator and fuel cell as sources and a lithium ion battery for energy source. These sources are connected to a 120 B DC link through DC-DC converters. Then the system is connected to the grid through an inverter and transformer. The system is controlled using an FPGA based controller and LabVIEW software This system has been provided by Ecosense Sustainable Solutions Pvt. Ltd, Delhi.

Components in the microgrid – 1. Wind turbineemulator 2. PV emulator 3. Fuel cell 4. Battery 5. DC-DC converters 6. Inverter 7. Transformer

Photo of the complete microgrid system

These two system have been combined to get different combination of sources and with the grid through inverter.

Experimental setup of a PV – Fuel Cell – Elctrolyser based hybrid system using three phase inverter - 1. Computer for hosting dSPACE software 2. dSPACE MicroLabBox 3. DSO 4. Power Quality Analyser 5. Power Logger 6. 3Φ voltage source inverter 7. DC link measurement 8. DC supply for gate driver circuit 9. DC supply for sensors 10. 3Φ grid 11. Gate driver circuit 12. Current sensor 13. Voltage sensor 14. Interfacing inductor 15. RC filter 16. Non linear load 17. DC-DC converters 18. Solar PV Emulator 19. Fuel cell 20. Dump load (Electrolyser)

3) Grid Connected Single Phase Inverter with Power Quality Improvement

Similar to the three phase inverter, this single phase inveter was assembled using Semikron inverter module (single phase), LEM sensors (voltage and current measurement), 6N136 based gate drive, interfacing inductor and RC ripple filter.

Photo of grid connected Single phase inverter

4) Bldc Motor control using DSP based controller

A BLDC motor sontrol sytem for a 1 kW motor was developed using battery bank, DC-DC converter and inverter. The system was controlled using a DSP controller (TMS320F28335).

Academic Year No. of first year Students intake in the year No.of first year students admitted in the year Academic Year No. of students graduating in minimum stipulated time No. of placed students Medium salary of placed graduates (Amount in Rs.) No. of students selected for higher studies
2019-2020 18 8 2020-2021 8 7 7.37 Lakhs/annum 0
2020-2021 18 12 2021-2022 12 9 7.35 Lakhs/annum 0
2021-2022 18 4 2022-2023 4 1 12 lakhs/annum 0
